T-250310-BHT-1 · Solar Trailer Model A · Rev A
Electrical Reference
Interactive Chinese → English lookup for the Whole Vehicle Electrical System Diagram. Search by Chinese text, English term, designator, or location.
Wire Gauge Reference4 cable sizes used in this diagram
4 mm²
Max: 32 A
PV array strings (solar panel to inverter)
Suitable for low-current DC solar circuits up to ~32 A.
6 mm²
Max: 46 A
Generator & ATS AC feeds, charger input
Used on AC circuits from the generator and mains inlet.
10 mm²
Max: 63 A
DC-DC converter output, 12 V distribution runs
Medium-duty DC runs from the 48 V→12 V converter.
50 mm²
Max: 170 A
Main battery bus (QF1 150 A breaker)
Heavy-duty DC bus cable rated to carry full 150 A load.
